The pulleys are supplied as semi-finished products and the bore must be modified before mounting the pulleys on the shafts. For higher speeds is essential dynamic balancing can be provided on request.
V Belt Pulley Sheave Sizes Table Chart Engineers Edge
China pulleys manufacturer we Specialise in.
Standard v belt pulley dimensions. 8C 8 9 1 0 B 4. European Series V-Belt Pulleys American Standard Sheaves Timing Belt Pulleys. Some narrow v-belts can operate at speeds of up to 10000 ftmin but these pulleys must be dynamically stabilized.
Cast Iron DIN 1691 GG20 GG25. Belt series Pitch Diameter Range Groove Angle Dimensions a W WbD X S E. The V-belt pulley design is based on DIN 2211 and ISO 4183 standards.
V and Flat Belt Design and Engineering Data. Running in normal standard the pulleys are statically balanced and this is sufficient for peripheral speeds up to 25 ms. 2BK55H V-Belt Pulleys - 4L or A 5L or B Belt Section 2 Groove 47000 in A 52000 in B Pitch Dia 52500 in OD Split Taper Bushed H Series Bushing Cast Iron Material MI.
Identifying a Poly-V Belt To size up a Poly-V belt the following information must be known. There are three common V belt types. The pulley dimensions are very accurate as they are manufactured by means of CNC or.
BSPB 1 to 6 belt grooves 1251000 pcd. Mm mm mm mm mm mm SPZ Up to 80 34 97 85 11 2 12 8 Over 80 38 SPA Up to 118 34 127 11 138 275 15 10 Over 118 38 SPB Up to 190 34 162 14 175 35 17 125 Over 190 38 SPC Up to 315 34 22 19 238 48 255 17 Over 315 38 Belt series Pitch. 34 Prrlley Pitch Diameter dp.
46 optibelt KS V-Grooved Pulleys Types. Number of Grooves The pitch diameter of the pulley Belt Profile. CSPC 210 belts run groove 2001250mm pcd.
Z A B C D E section V belts are measured with an internal length and the SPZ SPA SPB SPC and the XPZ XPA XPB and XPC section V belts are measured externally including cog section V belts which are toothed and denoted with an X. They are produced in standard series and dimensions. This is the distance from the centre of one groove to the centre of the next groove.
11 138 175 c. V-belts take this measurement from the widest point of the trapezoid. Number of Grooves The pitch length of the belt expressed in inches.
Universal V-Belt Pulleys ensures more mileage form V-belt drives in a way pulley is made from superior quality graded cast iron with grooves property machined with or without dynamic balancing that saves time in fixing. For timing pulleys this is the measurement between the flanges. Their counterpart cogged belt is classified by the letter X.
33 Pulley Groove Pitch Width I The width of the pulley grooves which is dimen- sionally the same as the pitch width o zhe belt associated with the pulley. Removal eliminates re-building or surface reboring. Classical V-belt classified by their dimensions from A to E Narrow V series classified by their dimensions 3V 5V and 8V and light duty Fractional Horsepower belt classified by their dimensions 2L 3L 4L 5L.
The belts chains or rope sizes that will fit into the pulley. Taper Lock Dynamically Balanced Dual Duty v belt pulleys ASPA section 1 to 6 grooves 80800mm pitch circle dia p cd or Outer Diameter. V-Belt Pulley Sheave Sizes Table Chart.
To identify a Vee Pulley the following information must be known. 45 PRODUCT DESCRIPTION METAL optibelt KS V-Grooved Pulleys optibelt TB Taper Bushes. V-P U L L E YS Dimension of grooves DIN 2211 Dimension of grooves of V-Pulleys suitable for banded belts RMA Section SPZ mm SPA mm SPB mm CSPC mm bw mm 85 110 140 190 b1 mm R02 97 127 163 220 c mm 20 28 35 48 e mm 12 R 03 15 R 03 19 R 04 255 R 05 f mm 8 R 06 10 R 06 125 R 08 17R1 t mm min.
Typically v-belt drives operate between 1500 to 6000 ftmin with 4500 ftmin the ideal capacity for standard belts. SPB Standard solid hub V-belt pulleysare the basic type of V-belt pulleys. The width of the belt at its neutral axis.
To learn more about how you can help Engineers Edge remain a free resource and not see advertising or this message please visit Membership. The different types or sections of V belt are measured slightly differently when it comes to their length. Standard Groove Sheave Widths.
The following table defiens industry standard V-Belt sheave grooves. Taper pulleys adjustable pulleys falt belts pulleys sheaves V-Belt Pullys for taper bushesV-Belt Pullys with solid hub. SPZ SPC Identifying a Vee Belt.
We have the capability to custom design and. Naismith Engineering stock the pulley profiles of SPA SPB and. Optibelt DK Double-Sided V-Belts Profiles AAHAA BBHBB CCHCC DDHDD 22 x 22 25 x 22.
CAST- IRON V-BELT PULLEYS All V-belt pulleys are compliant with current legislation and are made of cast iron GG 20 with protective phosphate. Naismith Engineering stock the pitch sizes of J L. V Belt Pulley Technical Specification TAPER LOCK HIC Manufactured UNIVERSAL Brand.
V-Pulley pulleys PCT oversized hub for Self Locking Units SIT-LOCK. They are made of gray cast iron. This is worked out by measuring the cross section of the belt and referring to pages 5 to 12.
Our V-Pulleys can be used for application with a speed up to 35 ms.
